Worm and helical geared motors and reducers
RW
The new REWO right-angle gear reducer is engineered to deliver the reliability of worm gear reducers with the efficiency of helical gears, optimizing the power transmission through more balanced load management and fitting perfectly a wide range of application requirements.
The RW series consists of three sizes: S, M, and L, offering a ratio range from 13 to 113 and nominal reference performance from 150 Nm to 450 Nm.
The aluminum casing features a compact, smooth design, allowing for installation in clean and hygienic applications, as well as confined spaces, while ensuring the gear reducer remains lightweight.
Warranty: Two years from date of delivery.
Characteristics
- REWO – Sizes S, M, L
- Available in the following version: with provision for motor mounting
- Available for flange mounting or shaft mounting
- Performance ratios between 13 and 113
- Nominal performance range from 150 to 450 Nm
- Unpainted aluminium casing, designed to meet high hygiene standards thanks to its clean, rib- and fin-free design
- Case-hardened/hardened steel worm screw and CuSn12Ni2 bronze wheel (UNI 7013-10)
- Ground ZI screw profile (UNI 4760)
- Case-hardened and tempered steel gears with a deburred or ground profile
- Loading capacity in accordance with: ISO 14521, DIN 3996, BS 721, AGMA 6034, ISO 6336, DIN 3990, DIN 743, ISO 281
- Options: protective cover, torque arm, outlet flange, output shaft kit, Viton sealing rings, lubricants for high/low temperatures and for the food industry
