Helical gear reducers - aluminium

HA - IHA - CHA

Helical gear reducers - aluminium

  • HA52pam90B5_CAM1 maxi
  • HA31_NMRV040_T63B5_CAM1 maxi
  • HA31-140x16x40-pam140x11_CAM1 maxi
  • HA31-140x16x40-pam140x11_T63B5_CAM1 maxi
  • HA51F-pam90B5_CAM 1 maxi
  • HA52Fpam90B5_CAM1 maxi
  • HA52Fpam90B5-T090S_CAM1 maxi
  • HA52pam90B5-T090S_CAM1 maxi
  • HA53Fpam90B5_CAM1 maxi
  • HA53Fpam90B5-T090S_CAM1 maxi
  • HA53pam90B5_CAM1 maxi
  • HA53pam90B5-T090S_CAM1 maxi
  • HA53U-Pam90B5_CAM1 maxi
  • HA53U-Pam90B5-T090S_CAM1 maxi
  • CHA52F-T090S_CAM1 maxi
  • CHA52-T090S_CAM1 maxi
  • CHA53F-T090S_CAM1 maxi
  • IHA52_CAM1 maxi
  • IHA52F_CAM1 maxi
  • IHA53_CAM1 maxi
  • IHA53F_CAM1 maxi

Designed to offer maximum reliability even in the harshest operating conditions, the HA product series guarantees complete versatility and is suitable for applications that require high radial loads.

The H-series includes a large number of extremely versatile models, in cast iron (sizes 030 to 140) or aluminium (sizes A30 to A60) casing.

Certifications Available: ATEX 3GD

Warranty: Two years from date of delivery.

Characteristics
Range
Downloads
PRODUCT CHECK LIST
Request more info
  • Sizes: A30-A40-A50-A60
  • Available versions: HA - fitted for motor coupling, IHA - with input shaft, CHA - with compact motor
  • Casing with feet, flange F or universal U
  • Power up to 5,5 kW
  • Gears hardened and tempered with shaved or ground profile
  • Gearing with 1, 2 and 3 reduction stages
  • Reduction ratios between 1,33 and 353,98
  • Torque max 500 Nm and admissible radial loads max 8.000 N
  • Cases in die-cast aluminium alloy
  • Load capacity calculated to ISO 6336 and verified according to AGMA 2001
  • Painted with RAL 5010 blue epoxy-polyester powder
